APL-2Nseries
- Enclosure:Aluminum Die-casting,weather proof-IP67/NEMA 4&4×
- Swithches:2×SPDT mechanical switch or proximity
- Cable Entry:2×1/2"NPT(std.).Option:M20,PG13.5,PF1/2",PT1/2"
- Terminal Strip:8 points(0.08-2.5mm2)
- Easy mounting,Namur standard,stainless steel bracket & bolts
|
|
|
APL 310 Series.Weather-Proof
- Enclosure:Aluminum Die-casting,weather proof-IP67/NEMA 4&4×
- Bolts on visual position indicator
- Swithches:2×SPDT mechanical switch or proximity
- Cable Entry:2×1/2"NPT(std.).Option:M20,PG13.5,PF1/2",PT1/2"
- Terminal Strip:8 points(0.08-2.5mm2)
- Easy mounting,Namur standard,stainless steel bracket & bolts
|
|
|
APL 410 Series.EX-Proof(EEXDII BT6)
- Enclosure:Aluminum Die-casting,weather proof-IP67/NEMA 4&4×&Explosion proof-EExdIIBT6
- Bolts on visual position indicator
- Swithches:2,3 or 4 ×SPDT mechanical switch or proximity
Option:Potentiometer(0-1,5,10K ohm).Position Transmitter(4-20mADC)
- Cable Entry:2×3/4"NPT(std.).Option:M20,M25,PF3/4",PT3/4"
- Terminal Strip:8 points(0.08-2.5mm2).Option:8-16 points
- Easy mounting,Namur standard,stainless steel bracket & bolts
|
|
|
APL 510 Series.EX-Proof(EEXDII CT6)
- Enclosure:Aluminum Die-casting,weather proof-IP67/NEMA 4&4×
- Bolts on visual position indicator
- Swithches:2×SPDT mechanical switch or proximity
- Cable Entry:2×1/2"NPT(std.).Option:M20,PG13.5,PF3/4",PT3/4"
- Terminal Strip:8 points(0.08-2.5mm2)
- Easy mounting,Namur standard,stainless steel bracket & bolts
|
|
|
APL 110 Series.Weather-Proof
- Enclosure:ABS plastic,weather proof-IP67/NEMA 4&4×
- Visual position indicator
- Swithches:2×SPDT magnet reed switch, LED indicator
- 0.7 meter lead wire(std.),option:quick coupler
- Easy mounting,Namur standard,stainless steel bracket & bolts
|
